The Dynemech Mild Steel Anti-Vibration Table AVT (P-83-01-B) is an essential accessory for laboratory environments that require a stable and vibration-free workspace. With its robust granite base measuring L 1000 X B 600 X T 50 mm, and a 60 mm tubular structure (65 X 65 mm), this anti-vibration table is designed specifically to meet the challenges presented by industrial units that generate significant vibration from machinery such as hammers and Vertical Machining Centers (VMCs). This table promotes precise analytical results by mitigating the impacts of external vibrations, making it ideal for testing and quality laboratories. The table features eight AV pads strategically positioned for optimal vibration absorption. It comes equipped with a front keyboard panel that includes a laser-cut pocket for joystick operation, adding convenience for users. Furthermore, an additional printer stand is integrated into the design, with the dimensions of 600X600 mm, allowing users to neatly house their CPU console, monitor, keyboard, mouse, and provide a pull-out tray for easy printer access. The table’s granite surface plate is crafted with Grade-1 accuracy, ensuring the highest level of precision and reliability in measurements. Designed for compatibility with analytical balances and scale controls, the Dynemech Anti-Vibration Table is available with customizable damping options, including Elastomeric, Pneumatic, or Spring-based systems, for effective vibration control based on laboratory needs. With levelling feet included for easy adjustments, it guarantees a stable and accurate platform for all your laboratory tasks.
Key Features
Features | Description |
---|---|
Granite Base Size | L 1000 X B 600 X T 50 mm |
Tubular Structure Size | 60 mm with 65 X 65 mm dimensions |
Anti-Vibration Pads | 8 AV pads for enhanced vibration absorption |
Keyboard Panel | Front mounted with laser cut joystick pocket |
Printer Stand | Dimensions 600 X 600 mm with a pull-out tray |
Accuracy Level | Grade-1 accuracy granite surface plate |
Damping Options | Customizable: Elastomeric, Pneumatic or Spring Based |
Levelling Feet | Included for proper height adjustment and stability |
Recommended Usage | Ideal for testing and quality laboratories |
Attributes | Description |
---|---|
Material | Mild Steel with Granite Base |
Overall Dimensions | L 1000 X B 600 X H (depending on user requirements) |
AV Pad Placement | 8 strategically placed pads |
Cubicle System | Compatible with analytical balances and control scales |
Printer Stand Size | 600 X 600 mm |
Weight Capacity | Suitable for heavy laboratory equipment (capacity varies) |
Surface Finish | Smooth granite finish for accurate measurement |
Color Options | Customizable (upon request) |
*Disclaimer: This above description has been AI generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
Brand: DYNEMECH
Country of Origin: India
Granite base of size L 1000 X B 600 X T 50 mm
60 mm Tubular Structure
65 X 65 mm AV pads at 8 places
Front keyboard panel with laser cut joystick pocket for Joystick
Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm
Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.
Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.
Our Anti-Vibration Tables are designed with Granite Surface Plate with Grade-1 accuracy for critical measuring accuracies. Also, vibration damping in our Anti-Vibration tables are provided at two locations – below the granite table top and at the bottom usinglevelling feet which can help in proper levelling of the table as well as having insulation plate to remove any unwanted vibrations. Additionally, we can select Elastomeric, Pneumatic or Spring Based Damping depending upon the vibrations present in the Testing Laboratory.
Granite base of size L 1000 X B 600 X T 50 mm
60 mm Tubular Structure
65 X 65 mm AV pads at 8 places
Front keyboard panel with laser cut joystick pocket for Joystick
Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm
