Dynemech Systems Private Limited

 Dynemech Insulation Plates Dp2 are made from the compund of Nitrile Rubber, Cork, Synthetic Fibre which

at varying compositions gives different natural frequencies for providing vibration damping solution to

almost every machine tool. Also the Insulation Plates are resistant to fuels, lubricating oils, water etc.

Size :600x600x20mm

Load Capacity (Kg.):01 to 05

Natural Frequency (Hz):12-30

Thickness (mm):20

Coeff. of Friction:0.8

Shore A Hardness:40-45

Working Temp Range °C:-20 to +70

Material:Nitrile Rubber, Cork, Synthetic Fibre and Other High. Gread Compounds. Box Dimention: 25"x25"x4" Weight Of 04 Nos: 32 Kgs Number Of Box:01

Colour:Green, Grey,Black Amount Is -7800

https://vibrationmountsindia.com/

Dynemech Wedge Mounts Series DB is designed for machines which require precision leveling along with vibration reduction and are desired to be firmly mounted with the isolator or machines with high axial thrust and do require any anchoring to the floor.

These mounts provide 2 holes on the top plate of the wedge. The bolt which is supplied as a standard accessory with these wedge mounts can be fixed in any of these two holes. While installing the machine, the bolt can be fixed in the hole which makes sure that most of the wedge mount is covered by the leg/base of the machine.

Size :115x115x69mm

Load Capacity (Kg.):1800 Kg/pc To 9500Kg/pc Bolt Size: M16 X 2.0 X 150 Long

https://vibrationmountsindia.com/

Dynemech DL Series AV mounts used for light to medium weight machines suited to levelling screw support or having tapped hole in the base. Dynemech DLS Series AV Mounts, developed in stainless steel finds application in pharmaceutical food and beverages processing and packaing units, medical equipment manufacturing and chemical processing industries.Provide vibration isolation with complete hygienic seal and corrsion resistance.

Size :Dia-276(mm), Height-43(mm)

Load Capacity (Kg.):4200 Kg/pc

 Natural Frequency (Hz):18

Coeff. of Friction:0.9

Working Temp Range °C:-16 to 90

Weight ( Kg.):14

Material:Rubber+Cust Iron+Mild steel

Colour:Green & Dark Grey Box Dimension:14"x14"7" 04 Nos Weight is : 65 kgs Number Of Box:02

https://vibrationmountsindia.com/

Dynemech offers a variety of SCREW SUPPORT MOUNTS Series DLC to improve the design and performance of the machine tools to meet customer demand. Insulation plates having different load carrying capacities and different natural frequencies are assembled with screw support mounts to suit almost every industrial application.

Size :Dia-302(mm), Height-84(mm)

Load Capacity (Kg.):4200 Kg/pc

Bolt Size:M24x3.0X200mm Natural Frequency (Hz):18

Coeff. of Friction:0.8

Adj.(mm):18

Working Temp Range °C:-16 to 90

Weight ( Kg.):30

Material:Rubber+Cust Iron+Mild steel

Colour:Green & Dark Grey Box Dimension: 14"x14"7" 04 Nos Weight is :130 Kgs Number Of Boxes:4

https://vibrationmountsindia.com/

Dynemech Screw Support Mounts Series DLK are simple and effective vibration dampers for machines with respective holes in the base. These mounts offer both low frequency attenuation and stable machine levelling.

The DLK Series of Vibration damping and leveling mounts provide fast and easy installation of machines. These Anti-vibration mounts provide enhanced component finish/part tolerance and extend tool and machinery life. The machine mounts provide improved health protection and better structural safety. DLK series Anti-vibration mounts have steel body and are used for machines having mounting holes in the base.

https://vibrationmountsindia.com/

Note- Freight Charges will be excluded.

Dynemech Screw Support Mounts Series DLK are simple and effective vibration dampers for machines with respective holes in the base. These mounts offer both low frequency attenuation and stable machine levelling.

The DLK Series of Vibration damping and leveling mounts provide fast and easy installation of machines. These Anti-vibration mounts provide enhanced component finish/part tolerance and extend tool and machinery life. The machine mounts provide improved health protection and better structural safety. DLK series Anti-vibration mounts have steel body and are used for machines having mounting holes in the base. This leveling mount has a cover plate and dimpled bottom plate holding the insulation plate. Leveling is done by tightening the bolt which lifts the cover plate with the machine foot.

https://vibrationmountsindia.com/

Note- Freight Charges will be excluded.

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-1100 B-550 T-50 mm

60x60 mm HR tubular structure with cross member

4 nos DLP3 at ground level, 4 nos - 3” wheel

9 nos AV pad between structure and granite base Front keyboard panel provided for placing  keyboard & mouse over the surface with laser cut joystick pocket with top rim and Monitor Bracket on L.H Rear with swivelling and tilting fecility Structure- RAL 9002, Side sheet, door & Key board panel- Graphite Grey Brief Description

https://vibrationmountsindia.com/

Note- Freight Charges will be excluded.

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-900 B-600 T-50 mm

60x60 mm HR tubular structure with cross member

4 nos DLP3 at ground level, 4 nos - 3” wheel

9 nos AV pad between structure and granite base

Front double door

Wrap around construction

Front keyboard panel provided for placing

 keyboard & mouse over the surface

with laser cut joystick pocket with top rim and Monitor Bracket on L.H Rear with swivelling and Structure- RAL 9002,  tilting fecility Side sheet, door & Key board panel- Graphite Grey

https://vibrationmountsindia.com/

Note- Freight Charges will be excluded.

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-1100 B-550 T-50 mm

60x60 mm HR tubular structure with cross member

4 nos DLP3 at ground level, 4 nos - 3” wheel

9 nos AV pad between structure and granite base

Front keyboard panel provided for placing

 keyboard & mouse over the surface

with laser cut joystick pocket with top rim and Monitor Bracket on L.H Rear with swivelling and tilting fecility Structure- RAL 9002,  Side sheet, door & Key board panel- Graphite Grey

Note- Freight Charges will be excluded.

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-900 B-600 T-50 mm

60x60 mm HR tubular structure with cross member 4 nos DLP3 at ground level, 4 nos - 3” wheel

9 nos AV pad between structure and granite base

Front keyboard panel provided for placing  keyboard & mouse over the surface Monitor Bracket on L.H Rear with swivelling and tilting fecility Structure- RAL 9002, Side sheet, door & Key board panel- Graphite Grey.

https://vibrationmountsindia.com/

Note- Freight Charges will be excluded.

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-750 B-600 T-30 mm

60x60 mm HR tubular structure

4 nos DLP3 at ground level, 4 nos - 3” wheel 8 nos AV pad between structure and granite base Front keyboard panel provided for placing  keyboard & mouse over the surface Monitor Bracket on L.H Rear with swivelling and tilting fecility Structure- RAL 9002, Side sheet, door & Key board panel- Graphite Grey.

https://vibrationmountsindia.com/

Note- Freight Charges will be excluded.

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-1100 B-550 T-50 mm

60x60 mm HR tubular structure

4 nos DLP3 at ground level, 4 nos - 3” wheel

9 nos AV pad between structure and granite base

Front keyboard panel provided for placing

 keyboard & mouse over the surface Monitor Bracket on L.H Rear with swivelling and tilting fecility Structure- RAL 9002, Side sheet, door & Key board panel- Graphite Grey

Note- Freight Charges will be excluded.

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-950 B-750 T-50 mm

60x60 mm HR tubular structure

4 nos DLP3 at ground level, 6 nos - 4” wheel

13 nos AV pad between structure and granite base

Cable manager in R.H & rear side, power strip in

rear & drawing pouch L.H side Front double door Wrap around construction Structure- RAL 9002, Side sheet, door & Key board panel- Graphite Grey

Note- Freight Charges will be excluded.

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-800 B-950 T-100 mm

60x60 mm HR tubular structure

4 nos DLP3 at ground level, 6 nos - 4” wheel

13 nos AV pad between structure and granite base

Including 79-50 swing arm articulating assembly

for keeping the Keyboard, mouse and Monitor

Structure- RAL 9002,  Side sheet, door & Key board panel- Graphite Grey

https://vibrationmountsindia.com/

Note- Freight Charges will be excluded.

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Pocket size for C&B SD: 630 X 400 X 80mm

60x60 mm HR tubular structure

4 nos DLP3 at ground level, 4 nos - 3” wheel power strip in rear side

Rear L.H Al. profile 45X45X525mm with swiveling

bracket and special laser cut CNC folded swinging and

clamping arrangement for display unit

https://vibrationmountsindia.com/

Note- Freight Charges will be excluded.

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-1100 B-600 T-50 mm

60x60 mm HR tubular structure with cross member

4 nos DLP3 at ground level, 4 nos - 3” wheel

12 nos AV pad between structure and granite base Front double door  keyboard & mouse over the surface with laser cut joystick pocket with top rim and Front pivot jointed swivelling unit with data processor

Note- Freight Charges will be excluded.

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-750 B-600 T-30 mm

60x60 mm HR tubular structure with cross member

4 nos DLP3 at ground level, 4 nos - 3” wheel

8 nos AV pad between structure and granite base Front double door

 keyboard & mouse over the surface with laser cut joystick pocket with top rim and Front pivot jointed swivelling unit with data processor.

Note- Freight Charges will be excluded.

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Table surface area : L-910 B-610 H- 586 mm

Granite base of size: L-900 B-600 T-50 mm

60x60 mm HR tubular structure

4 nos DLP3 at ground level,4 nos - 3” wheel

9 nos AV pad between structure and granite base

Cable manager in R.H side, power strip in rear

Front single door, Wrap around construction

Cable manager in R.H side, power strip in rear

for keeping the Keyboard, mouse and Monitor

https://vibrationmountsindia.com/

Note- Freight Charges will be excluded.

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size: L-900 B-600 T-50 mm

60x60 mm HR tubular structure with cross member

Front keyboard panel for keyboard and mouse,

lasercut joystick pocket with top rim and Z-plates at bottom to lock joystick.

Note- Freight Charges will be excluded.

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Table surface area : L-760 B-610 H- 767 mm

Granite base of size: L-750 B-600 T-30 mm

60x60 mm HR tubular structure

4 nos DLP3 at ground level, 4 nos - 3” wheel 8 nos AV pad between structure and granite base

Cable manager in rear side, power strip in rear & drawing pouch L.H side

Front double door

Wrap around construction

Front keyboard panel provided for placing

 keyboard & mouse over the surface

Monitor Bracket can be fixed either

rear L.H, front L.H and front R.H side of structure

Note- Freight Charges will be excluded.

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size L 750 X B 600 X T 30 mm

60 mm Tubular Structure

Front keyboard panel with laser cut joystick pocket for Joystick Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm

Note- Freight Charges will be excluded.

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size L 1100 X B 600 X T 50 mm

60 mm Tubular Structure with cross member

Wrap Around Construction with left angular profile

Swiveling bracket for monitor

Front keyboard panel for keyboard and mouse, lasercut

joystick pocket for Joystick

Freight Will Be Extra

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size L 1100 X B 550 X T 50 mm

60 mm Tubular Structure with cross member to suit 1000 X 450 X 80 mm Granite Base

65 X 65 mm AV pads at 9 places

4 No’s DLP3 (AV disc with adjustable screws) at Ground Level 4 No’s – 3” Wheel

Leveling Ball, Spanner 24/27

Powder Coat, structure RAL 9002, side sheets and doors – graphite gray Instrument sticker

Overall dimensions: L 1120 X B 570 X H 730 (over granite base) mm

Freight Will Be Extra

https://vibrationmountsindia.com/

Dynemech’s Anti-Vibration Tables are ideal for Testing / Quality Laboratories co-located with industrial units having high degree of vibration due to working machines like presses, hammers, VMCs etc. An anti vibration table is designed for cooperation with analytical and laboratory balances or control scales.

Granite base of size L 1100 X B 600 X T 30 mm

60 mm Tubular Structure

65 X 65 mm AV pads at 8 places

4 No’s DLP3 (AV disc with adjustable screws) at Ground Level 4 No’s – 3” Wheel Front keyboard panel with laser cut joystick pocket for Joystick Additional printer stand to accommodate CPU console, monitor, keyboard and mouse. Pull out tray for printer. Printer stand Size 600X600mm.

Freight Will Be Extra
