Product details

Dynemech Precision Levelling Mounts Series-VHS-I Festofix are useful in leveling and aligning machinery to very strict tolerances, and making it possible to vary adjustments at any time, even under maximum load.Benefits include: build-in compensation for uneven areas in foundations and machine bases. These benefits make the VHS Series Festofix Levelling Wedges the "state-of-the-art" anchoring/alignment system.

Length:170(mm) To 350(mm) Width:108(mm) To 230(mm) Height:60(mm) To 138(mm) Recommended Load Capacity: 1000 Kg/pc To 12000 Kg/pc Max. Load(Kg/pc):9000 Kg/pc To 70000 Kg/pc L1(mm):91 To 180 D(mm):75 To145 (mm) h(mm):5 To 10 f(mm): 17 To 37 G(M12 To M36 a(mm):12 To 35 SW1: 19 To 32 SW2:10 To 18 e1:12.7 To 28.0 e2:26 To 46

4 Nos Weight ( Kg.): 15 kg

Material: Cast Iron & sheet Metal

Colour: Red/Dark Grey

4 Nos of Boxes: 1

4 Nos Box Size: 13"x8"x7

Delivery Time: 4-5 Days

Price:3823.2

Freight Will Be Extra

*****

Description provided by Dynemech Systems Private Limited.

Allows strict tolerances and adjustments even under maximum load.

Adapts to uneven areas in foundations and machine bases.

Made from durable cast iron and sheet metal.

Supports loads from 1,000 kg to 70,000 kg per piece.

Lengths available from 170 mm to 350 mm with varying heights.

Standard delivery period is 4-5 days.

Specifications

Length

170 mm to 350 mm

Width

108 mm to 230 mm

Height

60 mm to 138 mm

Recommended Load Capacity

1,000 kg/pc to 12,000 kg/pc

Max Load

9,000 kg/pc to 70,000 kg/pc

Weight

15 kg

Material

Cast Iron & Sheet Metal

Colour

Red/Dark Grey

Box Size

13" x 8" x 7"

Price

3240

Use cases

Category

testing instrument and equipment > measuring and gauging tools

Primary application

Brand

Not specified

Product type

Product

Logistics & handling

Lead time

On request

Packaging

As per buyer requirement

Storage condition

As recommended by supplier

Origin

India

Form

As listed by supplier

Commercials Dynemech Systems Private Limited

Minimum order

1 unit

Lead time

On request

Payment terms

As per negotiated commercial agreement

Frequently asked by buyers

What materials are used in the construction of the VHS-1 levelling mounts?

The VHS-1 levelling mounts are constructed from durable cast iron and sheet metal, ensuring long-lasting performance.

What is the maximum load capacity of a single VHS-1 levelling mount?

Each VHS-1 levelling mount can handle a maximum load capacity ranging from 9,000 kg to 70,000 kg, depending on the chosen variant.

How do I adjust the levelling mounts if my machine shifts?

The VHS-1 series allows for easy adjustments under maximum load, enabling precise realignment of your machinery to maintain strict tolerances.

Is there a specific range of dimensions for the VHS-1 mounts?

Yes, the VHS-1 mounts come in various lengths from 170 mm to 350 mm, widths of 108 mm to 230 mm, and heights of 60 mm to 138 mm.

What is the delivery timeframe for the VHS-1 levelling mounts?

The standard delivery period for the VHS-1 levelling mounts is 4-5 days from the date of the order.
