The Bio Rad CFX384 Touch Real-Time PCR Detection System is engineered for accurate and efficient real-time PCR applications in a high-throughput 384-well format. This state-of-the-art system is tailored for researchers requiring sophisticated optical detection paired with advanced temperature control capabilities. It incorporates powerful features such as a user-friendly LCD touchscreen for easy navigation, real-time monitoring of amplification traces, and the capability to conduct both singleplex and multiplex reactions with precision. Moreover, the CFX384 Touch integrates seamlessly with CFX Maestro Software, allowing for intuitive design and analysis of experiments from a connected computer. By utilizing innovative 4-color detection optics and robust thermal cycler performance, this system ensures reliable and reproducible qPCR results that propel your research efforts forward, enhancing productivity in genomic studies and diagnostics.
Key Features
| Features | Description |
|---|---|
| High-Throughput Format | 384-well format for increased sample capacity. |
| Touchscreen Interface | User-friendly 7-inch LCD touchscreen for easy access and real-time monitoring. |
| Advanced Detection Optics | Equipped with sensitive 4-color detection optics for enhanced result accuracy. |
| Robust Thermal Cycler | Fast ramp rates ensure efficient cycling with minimal delays. |
| Intuitive Software Integration | CFX Maestro Software for easy experiment design and detailed results analysis. |
| Multiplexing Capability | Up to four targets can be detected simultaneously. |
| Accurate Temperature Control | Temperature range of 4–100°C with ±0.2°C accuracy. |
| Dynamic Range | Capable of detecting 1 copy of target sequence with a dynamic range of 10 orders of magnitude. |
| Attributes | Description |
|---|---|
| Maximum Ramp Rate (°C/sec) | 2.5 |
| Average Ramp Rate (°C/sec) | 2 |
| Heating and Cooling Method | Peltier |
| Lid Temperature Range (°C) | 30–110 |
| Temperature Range (°C) | 4–100 |
| Accuracy (°C) | ±0.2 of programmed target at 90°C |
| Uniformity (°C) | ±0.3 well-to-well after 10 sec at target |
| Gradient Operational Range (°C) | 30–100 |
| Programmable Span (°C) | 1–24 |
| Excitation Wavelengths (nm) | 450–650 |
| Emission Wavelengths (nm) | 515–690 |
| Sensitivity | Detects 1 copy of target sequence in human genomic DNA. |
| Dynamic Range | 10 orders of magnitude. |
| Scan Time (All Channels, sec) | 1 |
Key Words
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
Brand: Bio Rad
Country Of Origin: India
Thermal Cycler
Maximum ramp rate, °C/sec
2.5
Average ramp rate, °C/sec
2
Heating and cooling method
Peltier
Lid, °C
30–110
Temperature
Range, °C
4–100
Accuracy, °C
±0.2 of programmed target at 90°C
Uniformity, °C
±0.3 well-to-well after 10 sec of arrival at target
Gradient
Operational range, °C
30–100
Programmable span, °C
1–24
Optical Detection
Excitation
5 filtered LEDs
Detection
5 filtered photodiodes
Range of excitation wavelengths, nm
450–650
Range of emission wavelengths, nm
515–690
Sensitivity
Detects 1 copy of target sequence in human genomic DNA
Dynamic range
10 orders of magnitude
Scan Time
All channels, sec
<20
FAM/SYBR® Green only, sec
8
Software
Sample capacity, wells
384
Sample size, µl
1–30 (5–30 recommended)
Communication interface
USB 2.0
Electrical approvals
IEC, CE
Dimensions (W x D x H), cm/in
33x56x36 / 13x22x14
Weight, kg/lb
22/48
