PVC Insulated Tape

PVC insulated electrical tape is a pressure-sensitive adhesive tape made from polyvinyl chloride (PVC) film coated with a rubber-based or acrylic adhesive. Manufactured extensively across India, it is primarily used for insulating, binding, and protecting electrical wires, cables, and connections in residential, commercial, and industrial applications.

Indian manufacturers produce electrical tape in compliance with IS 13360 and IEC 60454 standards, ensuring consistent dielectric strength, tensile properties, and flame retardancy. Standard tape width ranges from 12mm to 25mm, with thickness typically between 0.10mm and 0.20mm. Dielectric strength is rated at a minimum of 6–8 kV, making it suitable for low-voltage applications up to 1100V. The tape offers an operating temperature range of -10°C to 80°C and is available in a full range of colours — black, red, blue, green, yellow, and white — supporting phase identification and colour-coding in electrical installations.

Key performance properties include good elongation (up to 200%), strong adhesion, moisture resistance, and self-extinguishing flame-retardant characteristics. The tape is supplied in rolls of 10m to 20m on plastic cores. Leading Indian manufacturers include Ceat, 3M India, Anchor Electricals, Denso, and Lohmann. The product is widely exported to the Middle East, Africa, and Southeast Asia.
