The LIFTIT Ratchet Lever Hoist 3.2 Ton is an essential tool for industrial and commercial applications, designed to provide superior lifting, pulling, and tensioning capabilities. With a robust construction and a capacity of 3.2 tons, this ratchet lever hoist is ideal for tasks requiring precision and control when moving heavy loads. It features a hand-operated mechanism that allows the user to lift and lower objects smoothly and safely, making it particularly suited for horizontal pulling and tensioning applications. Whether in automotive repair for straightening bent chassis or in various construction projects, the LIFTIT Ratchet Lever Hoist stands out with its durable performance and reliability, ensuring your lifting needs are met with minimal effort and maximum efficiency.
Key Features
| Features | Description |
|---|---|
| Load Capacity | 3.2 tons |
| Lifting Height | 1.5 meters |
| Number of Chain Strands | 1 |
| Load Chain Diameter | 10 mm |
| Gross Weight | 21 kg |
| Effort Required to Lift Maximum Load | 320 N |
| Dimensions (A x B x C x D x H x L x K) | A = 200 mm, B = 120 mm, C = 190 mm, D = 45 mm, H = 450 mm, L = 400 mm, K = 38 mm |
| Extra Weight Meter of Extra Lift | 2.1 kg |
| Attributes | Description |
|---|---|
| Model | 3.2 Ton Ratchet Lever Hoist |
| Running Test Load | 4.5 Tonnes |
| Net Weight | 17.5 kg |
| Packing Size | 55 x 25 x 20 cm |
*Disclaimer: The above description has been AI-generated and has not been audited or verified for accuracy. It is recommended to verify product details independently before making any purchasing decisions.
Brand: LIFT IT
Country Of Origin: India
LIFTIT Ratchet Lever Hoists 3.2 tons
Capaicty LIFTIT Ratchet Lever Hoists Are A Form Of Hand Operated Chain Hoist Or Commonly Known As A Ratchet Puller Or Chain Pulling Device. Ideal For Lifting, Pulling And Tensioning Loads Up To 10 Tones.
We offer several ranges of quality industrial strength Ratchet Lever Hoists.
All of our Ratchet Pullers are chained to your desired height of lift
LIFTIT Ratchet Hoists lift and lower the load in a controlled manor when the user operates the ratchet handle which turns the gears that pass the chain through the hoist body and lift/lower the load depending upon which direction the lever is operated in.
Ratchet Lever hoists are mainly used in Horizontal Pulling and Tensioning Applications, like Straightening of Bent Chasis of Automobiles which have been Damaged in Accidents,
Model 3.0T
Capacity (TON) 3
Standard Lifting Height (M) 1.5
Running test Load (Tonnes) 45
E�ort required to lift max. Load. (N) 320
No. of Chain strand 1
Load Chian Dia. (MM) 10
Net / Gorss weight (KG) 17.5/21
Packing Size (CM) 55 x 25 X 20
Extra weight meter of extra lift (kg) 2.1
Dimensions (MM)
A = 200
B = 120
C = 190
D = 45
H = 450
L = 400
K = 38
