Product details

SALIENT FEATURES:

 Completely self - contained stand - alone unit.

 Built - in MOSFET and other necessary components.

 Built - in two isolated DC regulated power supplies with short circuit protection.

  0 - 20V (Variable).

  0 - 5V (Variable).

 Mains ON / OFF switch with LED indicator for supply “ON”.

 Multi - coloured sturdy 4mm test points are provided at various stages in the circuit to observe the waveforms, voltages and for necessary inter connections.

 Provision for connecting external voltmeter / current meter as per requirement.

 Housed in an elegant ergonomically designed powder coated metal cabinet with a well spread intelligently designed circuit layout on the front panel.

 Working on 230V, 50Hz, single phase AC mains.

 Panel Size : 8“ x 10”

ACCESSORIES:

 4mm - 4mm terminated, sturdy, spring loaded patch cords :

  Quantity : 01 numbers provided.

 Strongly supported by a comprehensive instruction manual complete with theory and operating details :

  Quantity : 01 number provided.


Description provided by Advance Electronic Industries.

Complete stand-alone MOSFET trainer kit with integrated components

Includes MOSFET and all necessary components for direct experimentation

Two isolated DC regulated supplies: 0-20V and 0-5V with short circuit protection

Multi-colored sturdy 4mm test points for easy waveform and voltage observation

Provision to connect external voltmeter and current meter

Operates on 230V, 50Hz, single phase AC mains

Ergonomically designed powder coated metal cabinet, panel size 8" x 10"

Mains ON/OFF switch with LED indicator

4mm-4mm spring loaded patch cord and detailed instruction manual

Specifications
Pinch Off Voltage (Vp)
Determined experimentally via transfer characteristics
Drain Current (Id) for zero gate voltage (IDSS)
Measured from output characteristic curves
Forward Transconductance (gm)
Calculated from graphical data of MOSFET characteristics
Dynamic Resistance
Derived from MOSFET output characteristics
Power Supply 1
0 – 20V variable DC with short circuit protection
Power Supply 2
0 – 5V variable DC with short circuit protection
Input Power
230V AC, 50 Hz, single phase
Panel Size
8 inches x 10 inches
Test Points
Multi-colored 4mm spring loaded
Accessories
4mm-4mm patch cord (1 number), Instruction manual (1 number)
Use cases
Category
consumer electronics > audio and video players > educational electronics
Primary application
Brand
Product type
Product
Logistics & handling
Lead time
On request
Packaging
As per buyer requirement
Storage condition
As recommended by supplier
Origin
India
Form
As listed by supplier
Commercials Advance Electronic Industries
Minimum order
1 Piece
Lead time
On request
Payment terms
As per negotiated commercial agreement
Frequently asked by buyers
How does the MOSFET Trainer allow for measurement of the pinch-off voltage and drain current (IDSS)?

The trainer provides built-in MOSFET circuitry and isolated variable DC power supplies allowing users to plot both transfer and output characteristics. From these graphs, the pinch-off voltage (Vp) and drain current at zero gate voltage (IDSS) can be determined experimentally.

What provisions does the trainer have for connecting external measurement equipment?

The MOSFET Trainer includes multi-colored 4mm sturdy test points and dedicated terminals to connect external voltmeters and ammeters to facilitate precise voltage and current measurements as per experimental needs.

What safety features are included in the MOSFET Trainer’s power supplies?

Both the 0-20V and 0-5V regulated DC power supplies are equipped with short circuit protection to ensure safe operation during experiments and to prevent damage to the trainer and MOSFET components.

Can the MOSFET Trainer be used on standard household electrical systems?

Yes, the trainer is designed to operate on standard 230V, 50Hz, single phase AC mains commonly available in most laboratory and educational institute settings.

Does the MOSFET Trainer come with all required accessories for hands-on training?

Yes, it includes a 4mm to 4mm spring-loaded patch cord for connections and a comprehensive instruction manual detailing the theory, operation, and experimental procedures.
