Image Sensor
1/2.8
Effective Pixels
1920(H) x 1080(V), 2 Megapixels
Resolution
2MP
S/N Ratio
More than 50dB
Minimum Illumination
Color: 0.005Lux@F1.6; B/W: 0.0005Lux@F1.6; 0Lux@F1.6 (IR on)
Focal Length
4.8mm~120mm
White Balance
Auto, ATW, Indoor, Outdoor, Manual
Focus Control
Auto / Manual
Angle of View
H: 62.8° ~ 2.6°
AGC Control
Auto / Manual
Back Light Compensation
BLC / HLC / WDR(120dB)
Optical Zoom
25X
Digital Zoom
16x
Pan Travel
0°~360° endless, Pan Speed: 0.1° ~ 200°/sec
Tilt Travel
-15° ~ 90° auto flip 180°, Tilt Speed: 0.1° ~120°/sec
Manual Speed
Pan: 0.1° ~200° /s; Tilt: 0.1° ~120° /s
Presets
300
Preset Speed
Pan: 240° /s; Tilt: 200° /s
Power up Action
Auto restore to previous PTZ and lens status after power failure
Idle Motion
Activate Preset/ Scan/ Tour/ Pattern if there is no command in the specified period
Day/Night: IR Cut Filter
Auto(ICR) / Color / B/W
Video Compression
H.265+/H.265/H.264+/H.264
Video Streaming
Main stream: 1080P/720P(1 ~ 25/30fps) Sub stream1: D1/CIF(1 ~ 25/30fps) Sub stream2: 720P/D1/CIF(1 ~ 25/30fps)
Audio Streaming
1/1 channel In/Out
Auto tracking
No
Networking
RJ-45 (10/100Base-T)
IVS
Tripwire, Intrusion,Abandoned/Missing, Face Detection
IVS
Yes
Protocols
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS,PPPOE,DDNS,FTP, IP Filter,QoS,Bonjour,802.1x, ONVIF Profile S&G, API
Alarm
2/1 channel In/Out
IR Range
100 Mtr.
Operating Temperature
-40ºC ~ 70ºC / Less than 95% RH
Smart Phone
iPhone, iPad, Android Phone
Memory Slot
Micro SD card 256GB
Weatherproof Standard
IP66
Power Source
DC 12V/3A, PoE+ (802.3at)
Power Consumption
13W, 22W (IR on)
Description provided by PiS PROVIDERS.
