Bulk Head Elbow

Name: Bulk Head Elbow
Brand: elpar
SKU: 7578753
Availability: InStoreOnly

Sold by elparindustries · Manufacturer, Contractor, Trader, Exporter · Pune, Maharashtra, India

Price

Price on request

In stock

Minimum order: 1 Numbers

Export Snapshot

MOQ

1 Numbers

Lead time

On request

Packaging

Standard export packaging

Shelf life / longevity

As per product specification

HS Code

87089900

Origin

India

Port of dispatch

On request

Export markets served

Values shown are for elparindustries.

Compliance & Certifications

EEPC REGISTRATION CERTIFCATE

Suitable for

Importers · Distributors · Wholesalers

Pune Dispatch on request FIEO member

elparindustries

Manufacturer, Contractor, Trader, Exporter · Pune, Maharashtra, India

Hydraulic Fittings

Registered address: PUNE, MAHARASHTRA, India. Industry: Others > Other.

View profile All products

Established

2006

Employees

11–30

GST

27ANGPS2324G1Z1

IEC code

ANGPS2324G

Export markets

GlobalLinker Member Since

May 2021

Turnover

10000001 - 50000000.

Incorporation Type

On request

EEPC REGISTRATION CERTIFCATE ISO 9001-2015 EEPC and FIEO Membership

Product details

What are the specifications of this product?

Overview

Bulkhead Elbow Connector for Panel-Mounted Fluid LinesProcess, Tolerance, and Interface FitThe bulkhead elbow provides a sealed 90° fluid passage through a panel or enclosure. It is designed for panel mounting with a threaded flange or nut on the rear face. Key selection items include sealing face geometry, thread standard, and elbow bore size to maintain required flow performance without leakage.Procurement & Supply TermsVolume production includes dimensional inspection and sealing verification. Packing is optimized to protect flanged faces and finished threads for transit.

Product Description

Application Fit Across Industrial Systems

Bulkhead elbows are used in instrument panels, hydraulic manifolds, and equipment housings to route fluid while maintaining panel integrity. Buyers evaluate mounting interface, sealing method, and pressure rating for the intended application.

Technical Attributes and Manufacturing Notes

Materials and finishing options are selected for fluid compatibility and environmental exposure. Critical attributes include thread standard, sealing face flatness, and elbow bore continuity. Machining tolerances and surface finish on sealing faces are verified during inspection to ensure reliable sealing once installed.

Lead Time and Documentation

Lead times vary by batch size and finishing. Dimensional reports and material certificates are available to support procurement validation. Protective packaging preserves sealing surfaces during shipping.

Submit Drawings for Quotation

Provide panel cut-out and mounting details to obtain a production quote and supply plan.

Frequently Asked Questions

Can this elbow be produced for different panel thicknesses and thread standards? Yes. Specify panel thickness, thread standard, and seal type with your drawing for a tailored quote. (moq_bulk_order)
What are the key pricing factors? Pricing depends on material choice, finish requirements, and inspection scope. Complex sealing finishes affect cost. (pricing_cost)
Which documentation is provided with batches? Dimensional inspection sheets and material certificates can be supplied. (certifications_compliance)
How are bulkhead elbows packaged for delivery? Sealing faces are protected and parts are packed in transit-safe cartons sized to quantity. (logistics_delivery)

Description provided by elparindustries.

Specifications

Standard	DIN 2353 / ISO 8434
Angle	90 degrees
Thread Types	BSP, NPT, JIC, Compression, Push-to-Connect
Pressure Range	Up to 6000 psi (material dependent)
Material Variants	Brass, Stainless Steel, Carbon Steel, Nylon, Plastic
Size Range	From 1/8" to 1" or metric equivalents
Seal Type	O-ring or sealing washer
Installation	Bulkhead mounting with locknut and sealing washer
Applications	Hydraulic systems, Pneumatic control panels, Fuel and coolant lines, Process instrumentation

Use cases

Category	Industrial Pipe Fittings > Elbow Fittings > Bulkhead Elbows
Primary application	Wholesale, distribution, and international sourcing
Brand	elpar
Product type	Product

Logistics & handling

Lead time	On request
Packaging	As per buyer requirement
Storage condition	As recommended by supplier
Origin	India
Form	As listed by supplier

Commercials (this seller)

Minimum order	1 Numbers
Lead time	On request
Payment terms	As per negotiated commercial agreement.
Checkout type	enquiry

Buyer questions

Frequently asked by buyers

Common questions B2B buyers ask before sourcing Bulk Head Elbow. Answers compiled from verified sellers' commercial terms and platform data.

Q: What thread types are available for the Bulkhead Elbow fitting?

A: The Bulkhead Elbow is available with BSP, NPT, JIC, compression, and push-to-connect thread options, allowing compatibility with various assemblies.

Q: Can the Bulkhead Elbow handle high-pressure systems?

A: Yes, depending on the material and size, the Bulkhead Elbow can withstand pressures up to 6000 psi, suitable for demanding hydraulic and pneumatic systems.

Q: How does the Bulkhead Elbow ensure leak-free installation through panels?

A: It features a locknut and sealing washer or O-ring, which together provide a secure, tight mounting and prevent fluid or gas leaks at the bulkhead penetration.

Q: Are customized Bulkhead Elbow fittings available?

A: Yes, we manufacture customized Bulkhead Elbows tailored to specific requirements, including non-standard sizes, materials, and thread types.

Q: What materials are offered for corrosion resistance?

A: Materials such as stainless steel and reinforced plastic versions offer excellent corrosion resistance for harsh or chemical environments.
