ACR1552U USB NFC Reader IV with Smart Card Reading Capabilities RFID ISO/IEC 18092 NFC, ISO 14443 Type A & B, ISO 15693, MIFARE FeliCa

Sold by RAVIRAJ Technologies · Service Provider , Manufacturer, Retailer, Trader, Distributor, Exporter, Importer, Merchant · Pune, Maharashtra, India

Price
₹ 73.68 /Unit
In stock
MRP ₹ 111.09
Inclusive of all taxes
You Save: ₹ 37.41
Minimum order: 1 Unit

Export Snapshot

MOQ
1 Unit
Lead time
On request
Packaging
Standard export packaging
Shelf life / longevity
As per product specification
HS Code
On request
Origin
India
Port of dispatch
On request
Export markets served
United States flag US United Kingdom flag GB United Arab Emirates flag AE
Values shown are for RAVIRAJ Technologies.
Compliance & Certifications
Suitable for

Importers · Distributors · Wholesalers

Know your supplier

RAVIRAJ Technologies is a Service Provider , Manufacturer, Retailer, Trader, Distributor, Exporter, Importer, Merchant based in Pune Maharashtra India.

Pune Dispatch on request Verified seller
RAVIRAJ Technologies logo

Service Provider , Manufacturer, Retailer, Trader, Distributor, Exporter, Importer, Merchant · Pune, Maharashtra, India

RAVIRAJ Technologies : We are best-selling gaming PCs, gaming laptops, gaming deals, gaming accessories and more from leading brands online at Lenovo, Dell HP ACER, Intel NUC mini pc, desktop computers & all-in-one PCs Computers Peripherals Licensed Software Servers Storage Networking Biometrics Surveillance IOT Whether you know exactly what you need, or want advice on electronics IT products selection, we will deliver the right IT hardware

Registered address: Pune, India. Industry: Computer Peripherals & IT > Computer Hardware & Peripherals.

Established
2004
Employees
1–10
GST
27AIPPP2684Q1Z5
IEC code
Not shared
Export markets
United States flag US United Kingdom flag GB United Arab Emirates flag AE
GlobalLinker Member Since
Sep 2020
Turnover
10000001 - 50000000.
Incorporation Type
On request
Product details

What are the specifications of this product?

Overview

The RFID ACR1552U USB NFC Reader IV is a versatile smart card reader with high-speed communication and extensive smart card support. Features CCID & PC/SC compliant High-speed communication up to 848 kbps Extensive smart card support USB firmware upgradability FIDO authentication support

Product Description

Unleash Secure Connectivity

Step into the future with our ACR1552U USB NFC Reader IV - the pinnacle of secure smart card reader technology. Now, experience seamless and ultra-fast communication with high-speed connectivity up to an impressive 848 kbps. Safeguard your sensitive information with advanced security features that ensure your data remains protected at all times.


Enhanced Smart Card Support

Unlock a world of possibilities with the extensive smart card support of our ACR1552U USB NFC Reader IV. Seamlessly compatible with CCID & PC/SC standards, this reader brings unparalleled convenience to your fingertips. Upgrade your device's firmware via USB for continued improvements and stay ahead of the curve with FIDO authentication support.


Innovative Contactless Technology

Dive into the future of contactless technology with the ACR1552U USB NFC Reader IV. Revolutionize the way you interact with smart cards by embracing the ease and efficiency of RFID. Explore the endless applications this cutting-edge reader offers, from secure transactions to streamlined access control - all at your fingertips.


Features
  • CCID & PC/SC compliant
  • High-speed communication up to 848 kbps
  • Extensive smart card support
  • USB firmware upgradability
  • FIDO authentication support



Physical Characteristics
Dimensions (mm) Main Body: 98 x 65 x 12.8 mm
Antenna size: 50 x 40 mm
Weight (g) 89 g
USB Interface
Protocol USB CCID
Connector Type USB Type-A (ACR1552U-M1), USB Type-C (ACR1552U-MF)
Power Source From USB port
Speed USB Full Speed (12 Mbps)
Cable Length 1m, Non-detachable
Contactless Smart Card Interface
Standard ISO/IEC 18092 NFC, ISO 14443 Type A & B, ISO 15693, MIFARE®, FeliCa
Protocol ISO 14443-4 Compliant Card, T=CL
MIFARE® Classic Card, T=CL
ISO 15693
ISO 18092 NFC Tags
FeliCa
SAM Card Interface
Number of Slots 1 Standard SIM-sized Card Slot
Standard ISO 7816 Class A (5V)
Protocol T=0; T=1
Built-in Peripherals
LED 1 bi-color: Blue and Green
Buzzer Yes
Other Features
Other Features Supported Card Types:
  • ISO 14443 Type A & B Parts 1-4, ISO 15693, ISO 18092 NFC, MIFARE®, FeliCa, SRI/SRIX, CTS, Innovatron, Picopass, Topaz Card
  NFC Features:
  • Smart Card Reader/Writer, Keyboard Emulation, Card Emulation
Firmware Upgrade Supported
Certifications/Compliance
Certifications/Compliance Certifications:
  • IEC/EN 62368, CE, UKCA, FCC, VCCI, KC, J-LIS, RoHS, REACH, WEEE, Microsoft® WHQL
Compliance:
  • USB CCID, PC/SC
Device Driver Operating System Support
Device Driver Operating System Support Windows®, Linux®, macOS, Android™, iOS/iPadOS (16 or above)

Description provided by RAVIRAJ Technologies.

Specifications

USB Interface Protocol USB CCID
Connector Type USB Type-A (ACR1552U-M1), USB Type-C (ACR1552U-MF)
Power Source Powered via USB port
Cable Length 1 meter, non-detachable
Contactless Smart Card Interface ISO/IEC 18092 NFC, ISO 14443 Type A & B, ISO 15693, MIFARE®, FeliCa
Card Slot 1 standard SIM-sized card slot
Protocols Supported ISO 14443-4, T=CL, MIFARE® Classic, ISO 15693, ISO 18092 NFC
Included Peripherals 1 bi-color LED (Blue and Green), Buzzer
Certifications IEC/EN 62368, CE, UKCA, FCC, VCCI, KC, J-LIS, RoHS, REACH, WEEE, Microsoft® WHQL
Compliance USB CCID, PC/SC

Use cases

Category consumer electronics > electronic accessories > card readers
Primary application Wholesale, distribution, and international sourcing
Brand Not specified
Product type Product

Logistics & handling

Lead time On request
Packaging As per buyer requirement
Storage condition As recommended by supplier
Origin India
Form As listed by supplier

Commercials (this seller)

Minimum order 1 Unit
Lead time On request
Payment terms As per negotiated commercial agreement.
Checkout type enquiry
Buyer questions

Frequently asked by buyers

Common questions B2B buyers ask before sourcing ACR1552U USB NFC Reader IV with Smart Card Reading Capabilities RFID ISO/IEC 18092 NFC, ISO 14443 Type A & B, ISO 15693, MIFARE FeliCa. Answers compiled from verified sellers' commercial terms and platform data.

Q: What type of smart cards can be used with the ACR1552U?
A: The ACR1552U supports various smart card types including ISO 14443 Type A & B, ISO 15693, MIFARE®, FeliCa, and NFC tags.
Q: How can I upgrade the firmware on the ACR1552U?
A: The firmware can be upgraded via the USB interface, allowing for ongoing improvements and feature enhancements.
Q: Is the ACR1552U compatible with mobile operating systems?
A: Yes, the ACR1552U is compatible with mobile operating systems, including Android™ and iOS/iPadOS (16 or above), provided the right drivers are installed.
Q: What is the significance of FIDO authentication in the ACR1552U?
A: FIDO authentication enhances the security of transactions by providing a strong, passwordless authentication mechanism, critical for sensitive data handling.
Q: What certifications does the ACR1552U hold?
A: The ACR1552U is certified under various standards such as IEC/EN 62368, CE, FCC, and RoHS, ensuring compliance with international quality and safety standards.
