M/S.JIRAWALA STEEL AND ENGINEERING COMPANY

STAINLESS STEEL ROUND BAR

Stainless Steel Round Bar Specification: ASTM A276 / A479, ASME SA276 / A479

Grades : SS 300,SS 200,SS 400 series , 904L, Nickel Alloys Monel, Inconel, Hastelloy, Duplex, Super Duplex.

 SS 304/304L/304H//309/310/310S/316/316L/316Ti/317/317L/321/321H/
347/347H/409/410/420/430/431/440A/440B/440C/446/904L/15-5PH/17-4PH

Dimension Standard :EN, DIN, JIS, ASTM, BS, ASME, AISI
Size :1mm- 400mm Thickness
length: 50 mm to 6000 mm Long,1 To 6 Meters, Custom Cut Length
Finish: bright, export bright, black, forged etc.

Specification of Nickel 200/201 Round Bar

Nickel Round Bar Specification: ASTM B160, ASME SB160
Dimension Standard : EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 14mm-300mm
Length : 50 mm to 6000 mm Long,  1 To 6 Meters, Custom Cut Length
Form : Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.

Specification of Carbon Steel Round Bar

Standards :ASTM, ASME, AISI, EN, IS, ETC
Grades :IS 2062 GR.A/B, A/SA105, A/SA 350 GR. LF 1/ LF 2 /LF 3 /LF 5/ LF 6/ LF 9, A/SA 516 GR.60/65/70 , C 45, EN 8, EN 9, P235GH, ASTM A131 GR.A/B/D/E , AH/DH/EH 32/36/40, ETC
Range :3 MM TO 350 MM DIA
Finish :Bright, Polish & Black
Form :Round, Square, Hex (A/F), Rectangle, Wire (Coil Form), Wire-mesh, Billet, Ingot, Forging Etc.
Application :Framework, Braces, Supports, Shafting, Axles, Marine and etc.

COPPER ROUND BAR

Size : 3mm-300mm
Length :50 mm to 6000 mm Long, 1 To 6 Meters, Custom Cut Length

Aluminium Round Bars/Rodsare used in many general purposes such as nuclear reactors, cryogenic storage tanks, pollution control components, gas turbine parts, marine engineering, aircraft components, gas drilling, rocket motors, pumps, and many production industries. These bars and rods are applicable in various industries offshore oil drilling companies, power generation, gas processing, chemical processing, pharmaceuticals, chemical equipment, pharmaceutical equipment, sweater equipment, heat exchanger, paper industry, dairy industry, mining, and pulp industry.

Specification of Aluminium Round Bar

Aluminium Round Bar Specification :ASTM B211, ASME SB211
Dimension Standard :EN, DIN, JIS, ASTM, BS, ASME, AISI
Size :14mm-300mm
Length :50 mm to 6000 mm Long,1 To 6 Meters, Custom Cut Length
Form :Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.

Specification of Titanium Round Bar

Titanium Round Bar Specification:ASTM B348 / ASME SB348, ASTM B863 / SB863
Dimension Standard:EN, DIN, JIS, ASTM, BS, ASME, AISI
Size:1mm-300mm
Length: 50 mm to 6000 mm Long, 1 To 6 Meters, Custom Cut Length
Form:Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.

Specification of Inconel 600/601/625/718 Round Bar

Inconel Round Bar Specification:ASTM B166, ASME SB166
Dimension Standard:EN, DIN, JIS, ASTM, BS, ASME, AISI
Size:14mm-300mm
Length: 50 mm to 6000 mm Long, 1 To 6 Meters, Custom Cut Length
Form:Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.

Specification of Super Duplex Steel S32750/S32760 Round Bar

Super Duplex Steel Round Bar Specification :ASTM A276 / A479, ASME SA276 / A479
Dimension Standard :EN, DIN, JIS, ASTM, BS, ASME, AISI
Size :14mm-300mm
Length :50 mm to 6000 mm Long, 1 To 6 Meters, Custom Cut Length
Form :Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.

Specification of Duplex Steel S31803/S32205 Round Bar

Duplex Steel Round Bar Specification :ASTM A276 / A479, ASME SA276 / A479
Dimension Standard :EN, DIN, JIS, ASTM, BS, ASME, AISI
Size :14mm-300mm
Length :50 mm to 6000 mm Long, 1 To 6 Meters, Custom Cut Length
Form :Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.

Stainless Steel Butt-weld Pipe Fittings Types

    Elbow
    Tee
    Eccentric Reducer
    Concentric Reducer
    Long Stub End
    Short Stub End
    Cap
    Cross
    Pipe End

Specification of Stainless Steel Butt-weld Fittings

Specifications:ASTM A403 / ASME SA403

Grades : 304/304L/304H/309/310/310S/316/316L/316Ti/317/317L/321/321H/347/347H/904
Dimensions :ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Seamless Butt Weld Fittings : 1/2 - 10" | Welded Butt Weld Fittings : 1/2" - 48"

Haste alloy Butt-weld Pipe Fittings Types

    Elbow
    Tee
    Eccentric Reducer
    Concentric Reducer
    Long Stub End
    Short Stub End
    Cap
    Cross
    Pipe End

Specification of Hastelloy Alloy Buttweld Fittings

Specifications :ASTM B366 / ASME SB366
Dimensions :ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Seamless Butt Weld Fittings : 1/2 - 10" | Welded Butt Weld Fittings : 1/2" - 48"

Copper Nickel Alloy Butt-weld Pipe Fittings Types

    Elbow
    Tee
    Eccentric Reducer
    Concentric Reducer
    Long Stub End
    Short Stub End
    Cap
    Cross
    Pipe End

Specification of Copper Nickel 70/30 Buttweld Fittings

Specifications :ASTM B122, B171, B466, B467
Dimensions :ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Seamless Butt Weld Fittings : 1/2 - 10" | Welded Butt Weld Fittings : 1/2" - 48"

Copper Butt-weld Pipe Fittings Types

    Elbow
    Tee
    Eccentric Reducer
    Concentric Reducer
    Long Stub End
    Short Stub End
    Cap
    Cross
    Pipe End

Specification of Copper Buttweld Fittings

Specifications :ASTM B122, B171, B466, B467
Dimensions :ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Seamless Butt Weld Fittings : 1/2 - 10" | Welded Butt Weld Fittings : 1/2" - 48"

Carbon Steel Butt-weld Pipe Fittings Types

    Elbow
    Tee
    Eccentric Reducer
    Concentric Reducer
    Long Stub End
    Short Stub End
    Cap
    Cross
    Pipe End

Specification of Carbon Steel Buttweld Fittings

Cabon Steel Buttweld Fittings Standard :ASTM A234 Gr WPB ST37.2, ST35.8 Buttweld Fittings
Dimensions :ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size :Seamless Butt Weld Fittings : 1/2 - 10" | Welded Butt Weld Fittings : 1/2" - 48"

Specification of Monel 400/K500 Round Bar

Monel Round Bar Specification :ASTM B164 / A479, ASME SB164 / A479
Dimension Standard :EN, DIN, JIS, ASTM, BS, ASME, AISI
Size : 5mm-300mm
Length : 50 mm to 6000 mm Long, 1 To 6 Meters, Custom Cut Length
Form :Round, Square, Hex(A/F), Rectangle, Billet, Ingot, Forging Etc.

Specification of Stainless Steel Sheets and Plates:

Stainless Steel Sheets and Plates Specification :�ASTM A240 / ASME SA240.

Grades :SS 253MA/304/304L/304H/309/310/310S/316/316L/316Ti/317/317L/321/321H/
347/347H/409/410/420/430/446/904L

Above all we also stock SS 409, SS 410, SS 420, SS 430, SS 904L Sheets, Plates, Strips & Circles.
Dimension Standard :JIS, AISI, ASTM, GB, DIN, EN, etc
Width :1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm Custom as per requirement
Length :2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc Custom as per requirement
Thickness :0.3 mm to 120 mm
Form :Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Surface Finishing :Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.

STANDARD     UNS     WNR.     JIS     EN
Hastelloy C22     N06022     2.4602     NW 6022     NiCr21Mo14W
Hastelloy C276     N10276     2.4819     NW 0276     NiMo16Cr15W

Dimension Standard :JIS, AISI, ASTM, GB, DIN, EN, etc
Width :1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length :2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Thickness :0.3 mm to 120 mm
Form :Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.

Duplex steel grades S31803 (also known as 2205) and S32205 are highly versatile and widely used types of duplex stainless steel sheets and plates. They belong to the family of stainless steels that have a mixed microstructure of austenite and ferrite, typically in a roughly 50/50 ratio. This combination provides them with enhanced properties compared to standard austenitic or ferritic stainless steels.

Key Characteristics and Properties:
Composition:
S31803 (2205): Typically contains around 22% Chromium (Cr), 5-6% Nickel (Ni), 3% Molybdenum (Mo), and 0.14-0.20% Nitrogen (N).
S32205: This is an enhanced version of S31803 with a slightly higher Chromium content (22-23%), similar Nickel (4.5-6.5%) and Molybdenum (2.5-3.5%) content, and a similar Nitrogen range (0.08-0.20% or 0.14-0.20% depending on the specific standard). The higher Cr and often Mo and N contribute to slightly improved corrosion resistance.

Carbon steel sheets and plates are flat-rolled products composed mainly of iron and carbon, with small percentages of other elements like manganese, silicon, and copper. The carbon content is the primary determinant of the steel's properties.

Carbon Steel Sheets & Plates: Composition and Properties
Steel Sheets: Typically have a thickness of less than 6 mm (0.236 inches).
Steel Plates: Generally thicker than 6 mm (0.236 inches).
Carbon Content: Carbon steel is broadly classified based on its carbon content:
Low Carbon Steel (Mild Steel): 0.05% to 0.25% carbon. Known for its high ductility, toughness, machinability, and weldability. It is relatively low in cost and easy to form.
Medium Carbon Steel: 0.25% to 0.60% carbon. Offers a balance of strength and ductility, with improved hardenability compared to low carbon steel.

Aluminum and aluminum alloy sheets and plates are flat-rolled products available in various thicknesses and sizes, distinguished by their aluminum content and the addition of other elements to enhance specific properties.

Aluminum Sheets & Plates: Composition and Properties
Aluminum Sheets: Typically have a thickness ranging from 0.006 inches (0.15 mm) up to 0.249 inches (6.3 mm).
Aluminum Plates: Generally thicker than 0.250 inches (6.35 mm).
Pure Aluminum (1xxx series): These sheets and plates are made of 99% or more aluminum. They are known for:
Excellent corrosion resistance
High thermal and electrical conductivity
Good workability
Low strength

Aluminum Alloys (2xxx-8xxx series): Aluminum is often alloyed with other elements like copper, manganese, silicon, magnesium, zinc, and lithium to improve its strength, hardness, and other properties. Each series has a primary alloying


Specification of Titanium Sheets and Plates:

Titanium Sheets and Plates Specification :ASTM B265 / ASME SB265
Dimension Standard :JIS, AISI, ASTM, GB, DIN, EN, etc
Width :1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc custom as per requirement
Length :2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc custom as per requirement
Thickness :0.3 mm to 120 mm
Form :Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.

Stainless steel flange simplified as SS flange, it refers to the flanges that made of stainless steel. It is a mechanical component used primarily in piping systems to connect two sections of pipe or other equipment, providing a robust and reliable junction.
The common material standards and grades for stainless steel are ASTM A182 Grade F304/L and F316/L, with pressure ratings ranging from Class 150 to Class 2500. Stainless steel is utilized in more industries than carbon steel because it offers superior corrosion resistance and an aesthetically pleasing appearance.

304 Stainless Steel: General-purpose; good corrosion resistance.
316 Stainless Steel: Higher corrosion resistance, suitable for marine environments.
410 Stainless Steel: Martensitic; often used in applications requiring high strength.
Applications:
Oil and Gas: Used in pipelines and processing facilities.
Water Treatment: Common in systems handling potable water.
Chemical Processing: Essential for systems requiring low contamination and corrosion resistance.

Hastelloy flanges are pipe fittings designed for secure connections in corrosive environments, offering excellent resistance to a wide range of chemicals and high temperatures. They are made from Hastelloy, a nickel-based alloy, and come in various types like slip-on, weld-neck, and blind flanges, each suitable for different piping systems.
Key Features:
Corrosion Resistance:
Hastelloy flanges are known for their exceptional resistance to corrosion from a wide range of chemicals, including oxidizing and reducing agents.
High-Temperature Strength:
They can withstand high temperatures, making them suitable for various industrial applications.
Versatility:
Available in different types (slip-on, weld-neck, blind) and sizes, they can be used in various piping systems and applications.
Reliability:
They provide leak-free connections and are durable in challenging environments.

Carbon steel flanges are robust, cost-effective components used to connect pipes, valves, and other equipment in industrial settings. They are typically made from carbon steel, an iron-carbon alloy, and offer good strength, durability, and corrosion resistance. These flanges come in various types, including slip-on, weld neck, blind, and lap joint, each suited to different applications and construction methods.
Key Characteristics of Carbon Steel Flanges:
Strength and Durability:
Carbon steel provides a good balance of strength and toughness, allowing flanges to withstand the pressures and stresses of industrial piping systems.
Corrosion Resistance:
Carbon steel offers reasonable resistance to corrosion, making it suitable for many industrial environments.
Cost-Effectiveness:
Compared to other materials like stainless steel, carbon steel flanges are generally more affordable, making them a preferred choice for many applications.
Versatility:
Carbon steel flanges are available in various sizes, shapes, and face types (raised face, flat face, ring-type joint)
